Canine mitral valve disease, atrial fibrillation and congenital defects

With the publication of new American College of Veterinary Internal Medicine (ACVIM) consensus guidelines for the diagnosis and treatment of mitral valve disease (MVD)¹, therapy and diagnostic recommendations have been updated from the initial and original 2009 consensus.

MVD accounts for up to 75% of all heart diseases seen in practice. Most dogs that develop a murmur secondary to MVD will do so years before the onset of congestive heart failure (CHF), for those that progress to CHF.

In one study, approximately 70% of dogs with asymptomatic MVD were still alive at the end of the 6.5-year observation period². This means the majority of small-breed dogs with MVD either do not progress or progress slowly over years; therefore, management strategies and decision-making need to be stratified based on risk of progression.

The ACVIM consensus panel developed a staging system for MVD, which can be subdivided into those dogs that have asymptomatic MVD (stages A and B) and those with symptomatic MVD (with CHF; stages C and D). This sub-classification helps to further stratify the groups (Table 1).

Table 1. American College of Veterinary Internal Medicine staging system for mitral valve disease (MVD)
Stage	Description
Stage A	Dogs at high risk for developing heart disease, but have no identifiable signs of structural disease (for example, breeds predisposed to MVD, such as the cavalier King Charles spaniel).
Stage B	Dogs with structural heart disease (typical murmur with associated valvular changes), but have never developed clinical signs of heart failure. This stage can be further subdivided: Stage B1: asymptomatic dogs with MVD with no radiographic or echocardiographic evidence of cardiomegaly, with signs of cardiac remodelling (valvular changes, mitral regurgitation), but that do not meet clinical trial criteria to initiate therapy. Stage B2: asymptomatic dogs with more advanced MVD, with radiographic or echocardiographic evidence of cardiomegaly and cardiac remodelling (valvular changes, mitral regurgitation) that meet clinical trial criteria, where benefit of pharmacological treatment to delay progression to congestive heart failure (CHF) has been demonstrated.
Stage C	Symptomatic MVD dogs with either current or past clinical signs of CHF. Dogs may present as critical acute patients requiring hospital care, but may be able to be managed as an outpatient, dependent on the severity of clinical signs.
Stage D	Symptomatic, end-stage MVD patients with advanced CHF that is refractory to standard treatment.

This article discusses the treatment options available at the various stages of MVD, and, where appropriate, provides a class recommendation (class I being the highest) and level of evidence (LOE; strong being the highest, weak or expert opinion considered lower level of evidence).

In MVD disease, however, a number of treatments are based on expert opinion in the absence of good clinical trials. Treatments with high recommendation class or strong level of evidence are summarised in Table 2.

Table 2. Treatment recommendations for various American College of Veterinary Internal Medicine stages of mitral valve disease, with high level of recommendation or moderate-strong level of evidence to support use
Stage	Treatment
Stage A	No treatment is recommended.
Stage B	Stage B1: no treatment is recommended. Stage B2: pimobendan 0.2mg/kg to 0.3mg/kg every 12 hours.
Stage C	Acute (inpatient) Furosemide: 2mg/kg IV (or IM) every hour until respiratory rate improves, then reduce frequency. Constant-rate infusion (CRI) for life-threatening oedema or non-responsive oedema*. Free access to water Pimobendan 0.25mg/kg to 0.3mg/kg every 12 hours Oxygen supplementation, where required Thoracocentesis/abdominocentesis, where required Optimal nursing care Advanced treatments** Dobutamine CRI (2.5ug/kg/min to 10ug/kg/min) Sodium nitroprusside CRI (1ug/kg/min to 15ug/kg/min for up to 48 hours) Chronic (outpatient) Furosemide 2mg/kg orally every 12 hours, or as needed, to maintain patient CHF free (consider torasemide 0.1mg/kg to 0.3mg/kg every 24 hours) Angiotensin-converting enzyme inhibitors – benazepril or enalapril 0.5mg/kg orally every (12 hours to) 24 hours (off-label dose frequency) Spironolactone 2mg/kg orally every (12 hours to) 24 hours (off-label dose frequency) Pimobendan 0.25mg/kg to 0.3mg/kg orally every 12 hours Consideration of surgical intervention for mitral valve repair Optimal rate control of atrial fibrillation (when present) to a mean home heart rate of less than 125bpm
Stage D	Symptomatic, end-stage MVD patients with advanced CHF that is refractory to standard treatment. Acute (inpatient) As per stage C acute treatment, but also: Torasemide where furosemide resistance occurs Additionally to oxygen supplementation, ventilatory support/assistance may be required to allow medications to take effect Arterial vasodilators, where tolerable and titrated to effect based on blood pressure (amlodipine 0.05mg/kg to 0.1mg/kg orally as frequently as every three hours, or hydralazine 0.5mg/kg to 2mg/kg orally as frequently as every hour if indicated) Sildenafil 1mg/kg to 2mg/kg orally every eight hours if pulmonary hypertension is present Chronic (outpatient) As per stage C initially, but the following treatments are recommended: Torasemide where patients are refractory to furosemide (at a rate of 5% to 10% of total daily dose of furosemide, up to 0.6mg/kg/day) Other treatments are included in the consensus guidelines – readers are recommended to review this article and the published guidelines. Other treatments not included here either have lower class of recommendation or low level of evidence (weak or expert opinion)
*Low level of support for CRI. **Requires ICU monitoring.

Recommendations for stage A

• No revised recommendations have been made for stage A dogs.
• No treatment recommendations or dietary recommendations are made in the guidelines.
• Consider excluding breeding stock with murmurs at an age of between six and eight years.

Recommendations for stage B diagnostic procedures

Radiography may be beneficial (class I recommendation; LEO expert opinion) to assess for concurrent tracheal, bronchial and pulmonary disease.

Acquiring baseline radiographs may also allow clinicians to differentiate cardiac versus non-cardiac causes of future clinical signs, by having the patient’s previous radiographs for comparison.

Blood pressure should be considered in all patients and hypertension addressed if present, additionally to providing a baseline reading.

Echocardiography is recommended to fully assess the presence and severity of structural heart disease. Where echocardiography is unavailable, radiographs need to be interpreted with caution due to changes in thoracic conformation and breed differences in normal vertebral heart scales.

Recommendations for stage B1 management

Recommendations for stage B1 management remain unchanged from the 2009 guidelines:

• Treatment is not recommended, as progression to CHF from this early stage is uncertain.
• No drug or dietary treatment is recommended.
• Follow-up radiography every 6 to 12 months is recommended, with more frequent monitoring for large-breed MVD (which tends to follow a more rapid disease course)³.

Recommendations for stage B2 management

Stage B2 MVD dogs that meet the following criteria have been shown to benefit from therapy in large clinical trials⁴:

• Murmur intensity greater than or equal to 3 out of 6.
• Echocardiographic left atrial (LA) to aortic root diameter ratio (right parasternal short axis view; early diastole) greater than or equal to 1.6 (Figure 1a).
• Echocardiographic left ventricular internal diameter in diastole (normalised to bodyweight) greater than or equal to 1.7 (Figure 1b).
• Breed-adjusted radiographic vertebral heart score (VHS) greater than 10.5.



Ideally, all criteria should be met, but echocardiographic criteria provide the most reliable way to identify dogs where a treatment benefit is expected.

Where echocardiographic criteria is unavailable and radiography solely used, breed-adjusted VHS or a general-breed VHS greater than 11.5 could be used.

A new radiographic vertebral left atrial size measurement, with measurements greater than or equal to 3, is also likely to identify stage B2 MVD⁵.

Revised recommendations for stage B2 include:

• Pimobendan (0.25mg/kg to 0.3mg/kg every 12 hours; class I; LOE strong).
• Mild sodium restriction with a palatable diet and adequate protein levels (class IIa; LOE weak).
• Angiotensin-converting enzyme inhibitors (ACEis) may be considered where marked LA dilation or progressive LA dilation of serial monitoring is present (50% of consensus panel; class IIa in areas where ACEis are low cost; LOE weak); clinical trials for ACEis used in stage B have shown mixed results.
• Spironolactone is not recommended and recent early data (European College of Veterinary Internal Medicine Congress, 2019) has suggested no survival benefit for their use at this time.
• Other considerations include management of hypertension; consideration of surgical therapy in late stage B2 cases; and cough suppressants where infectious, inflammatory and cardiogenic oedema have been excluded.

Recommendations for stage C diagnostic procedures

The recommendation for the diagnosis of stage C MVD is the combination of echocardiography and radiography. The authors of this article also consider the use of lung ultrasound, a valid tool in an emergency setting where radiography is considered inappropriate if the patient is unstable⁶.

N-terminal pro-brain natriuretic peptide can also be considered; a normal or near-normal result in dogs demonstrating respiratory signs is highly likely to have a non-cardiac cause, rather than CHF, as the cause of clinical signs⁷.

Most dogs will be older patients, and assessment for comorbidities is recommended.

Recommendations for stage C management

Acute setting

In the acute setting, for hospital-based treatment, a furosemide treatment plan of 2mg/kg IV (or IM), followed by a further 2mg/kg every hour until a substantial improvement in respiratory rate and/or effort is seen, to a total dose of 8mg/kg in 4 hours, is recommended (class I recommendation, LOE expert opinion). For life-threatening or peracute pulmonary oedema, a furosemide constant-rate infusion (CRI; 0.66mg/kg/hour to 1mg/kg/hour) after the initial bolus(es) could be considered (class IIa; LOE weak). Free access to water is recommended.

In the acute setting, pimobendan (0.25mg/kg to 0.3mg/kg orally or IV) is recommended to improve haemodynamic status and reduce afterload.

According to the guidelines, ACEis may be used in the acute setting; however, the authors withhold these in acute management due to a potential additive effect with furosemide administration (preload reduction), which may lead to acute kidney injury in the acute setting.

ACEis are commonly added at discharge if minimal azotaemia is present, or one to two weeks following clinical re-examination and review.

Optimal nursing care – including urination monitoring, access to water, maintaining an appropriate environment and positioning of sedated patients – are all beneficial.

Oxygen supplementation, if required, can be supplied via an oxygen cage or incubator, or via nasal oxygen cannulas. These environments can become hot and humid, so the environment ideally requires temperature and humidity control – or close monitoring of humidity and temperature at a minimum – both of which can confound tachypnoea and dyspnoea.

Sedation should be considered if anxiety associated with dyspnoea is present. Butorphanol is most often recommended (0.2mg/kg to 0.25mg/kg IM or IV), but other narcotics and sedatives can be considered.

With all agents, monitoring of blood pressure and respiratory response to narcotics is suggested.

Other considerations for stage C inpatient therapy include sodium nitroprusside for fulminant oedema, dobutamine for patients with cardiogenic shock non-responsive to pimobendan, glyceryl trinitrate and arteriodilators (although one must take care to monitor for hypotension and renal injury). As these require close and extensive monitoring of clinical parameters, these are options generally reserved for referral centres.

Chronic setting

For chronic (home-based) treatment of stage C, quadruple therapy (spironolactone, pimobendan, ACEi and furosemide [or torasemide]; SPAF) is recommended at the onset of stage C. Chronic furosemide therapy for initial onset of stage C is typically 2mg/kg every 12 hours, but should be administered to effect.

The use of torasemide for first-line therapy is gaining popularity; doses of 0.1mg/kg to 0.3mg/kg have shown good success in managing early CHF⁸. Where oral furosemide dose reaches more than 8mg/kg/day when used in a SPAF protocol, patients are considered to be diuretic resistant and progress to stage D.

Measurement of urea, creatinine and electrolytes 3 to 14 days after starting or changing furosemide dose is recommended (class I; LOE weak). An ACEi (benazepril 0.5mg/kg every 12 to 24 hours) should be started at this time (if not already)⁹.

The authors may delay benazepril during initial acute management – for example, one to two weeks – where marked azotaemia and/or hypotension are present. Continue pimobendan (class I; LOE strong).

Spironolactone (2mg/kg every 12 to 24 hours) is recommended for its anti-aldosterone effects (class I; LOE moderate)¹⁰.

Beta blockers and nitroglycerin have limited to no indication in the chronic setting. Client home monitoring of respiratory rate, weight and appetite with home management is recommended (class I; LOE expert opinion).

Consideration of surgical intervention to repair the mitral valve apparatus in centres with low complication rates is encouraged where feasible (class I; LOE moderate).

In cases with atrial fibrillation (AF), drugs to consider include the combination of diltiazem (0.5mg/kg to 2mg/kg modified release every 8 hours) and digoxin (2.5ug/kg to 5.0ug/kg every 12 hours) as first line therapy – a mean Holter ECG heart rate of lower than 125bpm was considered to show good control and a survival advantage (class I; LOE moderate)¹¹.

Other considerations include cough suppressants and bronchodilators (class II; LOE expert opinion). The authors consider their use where CHF is under good control, but cough or respiratory signs are ongoing despite documented radiographic control of pulmonary oedema. These radiographs also help to exclude comorbidities.

Guidelines suggest moderate sodium restriction, monitoring urea, creatinine, and electrolytes (including magnesium, and both in late disease and if arrhythmias are present). Consider supplementation with omega-3 fatty acids if decreased appetite, muscle loss or arrhythmia occur (class IIa; LOE moderate).

Recommendations for stage D management

Revised recommendations for stage D management include:

• A lower degree of diuretic resistance before classifying as stage D (greater than 8mg/kg/day furosemide or equivalent torasemide dose, when used in a SPAF protocol as per stage C).
• Where AF is present, rates should be lower than 125bpm before considering refractory to standard therapy.
• Treatment consensus for stage D has lower levels of evidence due to the lack of clinical trials in this specific stage.

Acute setting

Stage D is diagnosed as per stage C, but with the addition of failure to respond to conventional SPAF protocol.

In an acute hospital-based setting, additional furosemide should be administered as IV boluses (2mg/kg every hour) for a maximum of four hours (class I; LOE expert opinion), or as a CRI (0.66mg/kg/hour to 1mg/kg/hour) until respiratory distress (rate and effort) has decreased. Alternatively, substitution for torasemide could be considered.

Cavity effusions should be removed to improve respiratory signs, where appropriate. If a patient can tolerate a reduction in afterload, arteriodilators should be considered. These can be given orally, but may require CRI administration IV, and referral to a cardiac or emergency and critical care unit is recommended by the authors if this option becomes necessary. Giving arteriodilators requires great caution as the combination of ACEis and arteriodilators can cause serious and life-threatening hypotension.

The benefits of afterload reduction outweigh the risk of hypotension in most cases, and in many cases “blood pressure reserve” exists to allow for titration to optimise the afterload reduction.

Other considerations are the management of pulmonary hypertension with sildenafil (1mg/kg to 2mg/kg orally every eight hours). Typically, this will be diagnosed with advanced echocardiography, but clinical signs – such as jugular distension or ascites with left-sided heart disease – may raise the suspicion for its presence.

Off-label use of pimobendan (for example, 0.3mg/kg every eight hours) could be considered (class IIa; LOE expert opinion).

Chronic setting

For chronic management of stage D patients, higher doses of diuretics may be required. With higher dosing comes increased risk of clinically relevant azotaemia and electrolyte imbalance; these should be monitored closely.

All doses of the SPAF protocol should be optimised to their upper limits and all treatments recommended for stage C should be continued in stage D (except if furosemide is substituted for torasemide – then torasemide dose should be adjusted according to clinical requirements).

For chronic management, sildenafil, arteriodilators (amlodipine and hydralazine) and off-label pimobendan (every eight hours) should be considered.

Hydrochlorothiazide (or co-amilozide) was a recommendation by several panellists on the consensus committee, but using very low starting doses (0.5mg/kg to 2mg/kg orally every 12 to 24 hours), and titrating slowly due to the potential for acute renal injury and electrolyte imbalances.

Moderate sodium restriction and maintained calorie intake, along with omega-3 fatty acids, were recommended for dietary management.

AF

AF is the most common non-physiological arrhythmia in dogs^12,13. It is characterised by a fast and irregular rhythm on auscultation, accompanied by pulse deficits. Its diagnosis is easily made by ECG, where the absence of P waves – in combination with an irregular R-to-R interval, QRS complexes with normal morphology and fast heart rate – are pathognomonic.

Occasionally a normal rate may be observed. This so-called “lone AF” tends to affect large-breed to giant-breed dogs, where the atria are large enough to sustain the arrhythmia, similar to the horse¹⁴.

Most commonly, however, AF develops in association with an underlying heart disease that leads to marked atrial enlargement.

Unsurprisingly, the prevalence of AF is higher in older large-breed dogs^12,13. An association between AF and dilated cardiomyopathy (DCM) is common – up to half of dogs with DCM are reported to also be affected by AF^15,16. However, also, approximately 52% of dogs with myxomatous MVD weighing more than 15kg appear to be affected by this arrhythmia¹⁷.

AF can be an incidental finding in some dogs (particularly if lone AF); however, most patients with AF will have an underlying heart disease and clinical signs associated with CHF – including lethargy, generalised weakness, exercise intolerance, anorexia, weight loss, dyspnoea, tachypnoea, coughing or even syncope¹⁸.

AF also appears to contribute to the development of right-sided CHF; this was detected in almost 73% of dogs with DCM (versus 40% of dogs with DCM without AF) and 76% of dogs with degenerative MVD (versus 7% of dogs without AF)¹⁶.

The development of AF in the presence of an underlying heart condition, carries a worse prognosis¹⁷. Conversion back to sinus rhythm – although physiologically desired – is an unrealistic goal as, in virtually all patients, AF returns within days to months^19-21.

Therefore, control of the heart rate is a more realistic aim. But a question remained until recently: what is the optimal heart rate for a dog with AF?

Some suggested a Holter-derived mean heart rate of lower than or equal to 140bpm could indicate an adequate rate control²². Others believe dogs in heart failure would benefit from having a higher heart rate when in AF to maintain an appropriate cardiac output²².

Recently, it was shown that in dogs with degenerative MVD, an ECG-derived heart rate lower than 160bpm was associated with longer survival time than a heart rate higher than 160bpm (171 days versus 61 days)¹⁷. However, a rate of 160bpm – or even 140bpm – is much higher than the heart rate of a normal dog²³, and it is nowadays widely accepted these faster heart rates will contribute to atrial remodelling and heart failure²⁴.

Another study has suggested dogs with a Holter-derived mean heart rate lower than 125bpm had longer survival time compared to dogs with a mean heart rate higher than 125bpm (1,037 days versus 105 days; Figure 2)¹¹. The same study also showed for every 10bpm decrease in mean heart rate, the risk of all-cause mortality decreased by 29%¹¹ – suggesting a clear benefit of lower heart rate within the normal sinus rhythm range.

An international multicentre prospective study is taking place to prospectively investigate the ideal rate control strategy.

Congenital diseases

Pulmonic stenosis (PS) and patent ductus arteriosus (PDA) are two of the most common congenital defects in dogs²⁵; both conditions can be managed effectively with minimally invasive procedures where indicated.

PS

In dogs with PS, the presence of clinical signs at admission has been reported to be one of the main factors with negative impact on the outcome^26,27. Younger age at diagnosis and valve morphology (type B – hypoplastic valve annulus) are other negative prognostic factors²⁷.

Dogs with severe PS (transvalvular pressure gradient [PG] greater than 80mmHg) are at risk for developing clinical signs of exercise intolerance, syncope or sudden death²⁶. Balloon valvuloplasty (BVP) is the recommended treatment in these cases, independently of clinical signs, or for any symptomatic dog with PS²⁶.

According to literature, of the dogs that underwent a BVP, only the presence of clinical signs was significant to the outcome²⁸; while of the dogs that did not have BVP, a higher PG, presence of tricuspid regurgitation, presence of clinical signs, valve morphology type B and younger age at diagnosis negatively affected survival^28-30.

But how successful are BVPs? According to Locatelli et al²⁷, the pre-BVP PG is the most important independent predictor of immediate and long-term outcome – the more severe the PS, the most likely the BVP results will be suboptimal.

However, the study aimed for a transvalvular PG lower than 50mmHg for the procedure to be considered successful²⁷, while many other groups would aim for a more realistic goal with a 50% reduction in PG³¹.

This is particularly important in dogs with very high PG; it is not uncommon to have PS with a PG greater than 150mmHg – in these cases, achieving a PG of 50mmHg would be overly optimistic in many instances.

This was, in fact, the aim of a prospective study using high-pressure balloons (rated burst pressure between 12atm and 18atm, higher than the balloons routinely used in other studies)³¹. This type of balloon provided a median PG reduction of 63% and was considered successful in 92% of the cases (either by achieving a reduction in PG of at least 50% or a reduction into the moderate PS category with a PG lower than 80mmHg)³¹.

In 56% of dogs, the post-BVP PG was lower than 30mmHg³¹. In this study, only pulmonary valve annulus diameter was significantly correlated to PG reduction (although the numbers were very low)³¹.

More recently, stent angioplasty has been shown to be a viable alternative for those rare cases with valvular PS where routine BVP is considered unsuccessful³².

However, when performed by an experienced operator, BVP tends to be a successful procedure for alleviating clinical signs and prolonging survival in dogs with severe PS^18,26.

Complications are rare; however, a report has showed 7% of the patients undergoing BVP suffered major complications, including cardiopulmonary arrest, malignant ventricular tachycardia refractory to pharmacological treatment, cardiac perforation resulting in pericardial effusion, balloon rupture with pulmonary arterial fragment embolisation or jugular venous embolisation, and inability to access the right ventricle with concurrent tricuspid valve stenosis; although many centres – including that of the authors – have much lower complication rates than these reported³³.

To avoid other major complications, it is also mandatory to rule out aberrant coronary arteries prior to a BVP, particularly in breeds where this anomaly has a higher prevalence – for example, bulldogs. These can be suspected based on echocardiography and diagnosed with an aortic root angiogram or CT angiography^26,34,35.

In these cases, a conservative BVP may be performed; however, results tend to be suboptimal³⁶.

PDA

A PDA is a vessel that connects the aorta to the pulmonary artery, allowing shunting of blood from the systemic to the pulmonary circulation, which, with time, may lead to volume overload of the left side of the heart.

The general recommendation is to close the PDA as soon as possible to avoid cardiac remodeling or even development of CHF – more than half of the dogs that do not undergo surgery will die within one year^37,38; when the PDA is closed early in life, animals can have a normal life expectancy³⁹. Many devices have been developed over time for minimally invasive PDA closure, with transvenous or transarterial approaches. Coils appear to have been largely replaced by Amplatz canine duct occluder (ACDO) devices^37,40.

Nowadays, coils are mainly reserved for very small patients – their smaller profile allows access through small-calibre vessels in smaller patients. However, the risk of dislodgement or incomplete occlusion makes the ACDO a much more attractive option⁴⁰.

In the attempt to override these limitations, new devices are being explored – low-profile ACDOs and Amplatzer vascular plugs (AVPs)^39,41. In the authors’ practice, human devices – such as a type-two AVP – have also been routinely used (unpublished data; Figure 3).

Additionally to the challenge the initial approach can represent due to the dimensions of the vascular access, correct sizing of the PDA ostium (or ampulla, depending on the type of device to be used) is another vital step.

It is important to use more than one modality to evaluate the size of the ostium and/or ampulla, as this is essential to guide the selection of the right size device. Unfortunately, it has been shown not even bodyweight can help predict the size of the PDA ostium⁴²; therefore, a good imaging technique is required.

The agreement between transthoracic echocardiography, transoesophageal echocardiography, angiography and 3D echocardiography is suboptimal; therefore, the modality that allows the best visualisation of the PDA for each case should be used for measurements and/or to guide the procedure⁴³.

In rare occasions, surgical ligation of the PDA is an alternative to consider – this decision is mainly based on patient size, availability of different techniques in the practice and, potentially, costs.

Similar success rates have been reported between surgical ligation and minimally invasive occlusion of the PDA; however, the latter is associated with fewer complications^33,44.

Embolisation of the device is one of the most reported – although rare – complications and is the main reason why temporary exercise restriction is recommended in the immediate postoperative period^33,44.

The diagnosis and consequent closure of a PDA tends to occur at a young age, when the loud continuous murmur is detected. However, in some cases, this can be missed and a PDA is, therefore, identified in older dogs. This is usually associated with cardiomegaly and clinical signs of CHF, which would still benefit from closure – even if other concurrent cardiac diseases are present⁴⁵.

• Some drugs mentioned are not licensed for veterinary use.
